Base class for a simple lexical scanner. More...

Inheritance diagram for aud.util.LexicalScanner:

Collaboration diagram for aud.util.LexicalScanner:

Classes
class	Rule
	a rule for lexical scanner

Public Member Functions
	LexicalScanner (Rule[] rules, String input)
	create new scanner processing `input @endiliteral` More...

void	setInput (String input)
	set input (resets scanner state) More...

String	matchedText ()
	get text of last `match` or call to `next` More...

int	matchedTokenId ()
	get result of last call to `next()` More...

String	remainder ()
	get remaining text More...

boolean	endOfInput ()
	reached end of input? More...

int	next ()
	match `remainder` to rules provided to constructor More...

Static Public Member Functions
static void	main (String[] args)
	testing and example for usage More...

Static Public Attributes
static final int	END_OF_INPUT = -1
	no more input More...

static final int	NO_MATCH = -2
	no match (usually implies a syntax error) More...

static final Pattern	P_WHITESPACE = Pattern.compile("\\s+")
	white space More...

static final Pattern	P_IDENTIFIER
	identifiers More...

static final Pattern	P_FLOAT
	floating point number More...

Protected Member Functions
void	eatWhiteSpace ()
	ignore white space (called by `match` More...

boolean	match (Pattern p)
	Match `remainder` against pattern `p`. More...

int	next (Rule[] rules)
	match `remainder` to table of `rules @endiliteral` More...

Detailed Description

Base class for a simple lexical scanner.

A lexical scanner splits input into tokens. Here, token types are referenced by integer constants given in a table of rules. Each token is characterized by a regular expression.

Note: java.util.Scanner is often a better choice. However, this requires definition of a delimiter, which is problematic in this context.

Definition at line 19 of file LexicalScanner.java.

Constructor & Destructor Documentation

◆ LexicalScanner()

aud.util.LexicalScanner.LexicalScanner	(	Rule[]	rules,
		String	input
	)

create new scanner processing input @endiliteral

Parameters

rules	table of rules used by `next`, rules will be applied sequentially in the given order
input	text to be analyzed

Definition at line 68 of file LexicalScanner.java.

                                                   {
    rules_=rules;
    input_=input;
  }

Member Function Documentation

◆ eatWhiteSpace()

void aud.util.LexicalScanner.eatWhiteSpace ( )

protected

ignore white space (called by match

Definition at line 74 of file LexicalScanner.java.

                                 {
    if (!endOfInput()) {
      Matcher m=P_WHITESPACE.matcher(input_);
      if (m.lookingAt()) {
        input_=input_.substring(m.end(),input_.length());
      }
    }
  }

References aud.util.LexicalScanner.endOfInput(), and aud.util.LexicalScanner.P_WHITESPACE.

Referenced by aud.util.LexicalScanner.next().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ endOfInput()

boolean aud.util.LexicalScanner.endOfInput ( )

reached end of input?

Definition at line 94 of file LexicalScanner.java.

                              {
    return input_==null || input_.length()==0;
  }

Referenced by aud.util.LexicalScanner.eatWhiteSpace(), and aud.util.LexicalScanner.next().

Here is the caller graph for this function:

◆ main()

static void aud.util.LexicalScanner.main ( String[] args )

static

testing and example for usage

Reimplemented in aud.example.expr.Tokenizer.

Definition at line 143 of file LexicalScanner.java.

                                         {

    Rule[] rules={
      new Rule(1,"[0-9]*\\.?[0-9]+"),
      new Rule(2,"[a-z]+")
    };

    LexicalScanner s=new LexicalScanner
      (rules,args.length==0 ? "  12.3a 12 bcd 34 " : args[0]);

    System.out.println("input = '"+s.remainder()+"'");

    while (s.next()!=END_OF_INPUT) {
      if (s.matchedTokenId()==NO_MATCH) {
        System.out.println("syntax error near '"+s.remainder()+"'");
        break;
      }
      System.out.println("next token id = "+s.matchedTokenId());
      System.out.println("matched text = '"+s.matchedText()+"'");
      System.out.println("remaining input = '"+s.remainder()+"'");
    }
  }

References aud.util.LexicalScanner.END_OF_INPUT, aud.util.LexicalScanner.matchedText(), aud.util.LexicalScanner.matchedTokenId(), aud.util.LexicalScanner.next(), aud.util.LexicalScanner.NO_MATCH, and aud.util.LexicalScanner.remainder().

Here is the call graph for this function:

◆ match()

boolean aud.util.LexicalScanner.match ( Pattern p )

protected

Match remainder against pattern p.

match skips any preceding white space.

Parameters

p	regular expression pattern

Returns: true if there was a match

Definition at line 103 of file LexicalScanner.java.

                                     {
    text_=null;
    eatWhiteSpace();

    if (endOfInput())
      return false;

   Matcher m=p.matcher(input_);
    if (!m.lookingAt())
      return false;

    int n=m.end();
    text_=input_.substring(0,n);
    input_=input_.substring(m.end(),input_.length());

    return true;
  }

◆ matchedText()

String aud.util.LexicalScanner.matchedText ( )

get text of last match or call to next

Definition at line 88 of file LexicalScanner.java.

88{ return text_; }

Referenced by aud.example.expr.Tokenizer.main(), and aud.util.LexicalScanner.main().

Here is the caller graph for this function:

◆ matchedTokenId()

int aud.util.LexicalScanner.matchedTokenId ( )

get result of last call to next()

Definition at line 90 of file LexicalScanner.java.

90{ return id_; }

Referenced by aud.example.expr.Tokenizer.main(), and aud.util.LexicalScanner.main().

Here is the caller graph for this function:

◆ next() [1/2]

int aud.util.LexicalScanner.next ( )

match remainder to rules provided to constructor

Returns: rule id or NO_MATCH or END_OF_INPUT

Definition at line 139 of file LexicalScanner.java.

139{ return next(rules_); }

aud.util.LexicalScanner.next

int next()

match remainder to rules provided to constructor

Definition: LexicalScanner.java:139

References aud.util.LexicalScanner.next().

Referenced by aud.util.LexicalScanner.next().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ next() [2/2]

int aud.util.LexicalScanner.next ( Rule[] rules )

protected

match remainder to table of rules @endiliteral

Returns: rule id or NO_MATCH or END_OF_INPUT

Definition at line 123 of file LexicalScanner.java.

                                   {
    eatWhiteSpace();

    if (endOfInput())  return id_=END_OF_INPUT;
    if (rules_==null)  return id_=NO_MATCH;

    for (Rule rule : rules) {
      if (match(rule.pattern_))
        return id_=rule.id_;
    }
    return id_=NO_MATCH;
  }

References aud.util.LexicalScanner.eatWhiteSpace(), and aud.util.LexicalScanner.endOfInput().

Referenced by aud.example.expr.Tokenizer.main(), and aud.util.LexicalScanner.main().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ remainder()

String aud.util.LexicalScanner.remainder ( )

get remaining text

Definition at line 92 of file LexicalScanner.java.

92{ return input_; }

Referenced by aud.example.expr.Tokenizer.main(), and aud.util.LexicalScanner.main().

Here is the caller graph for this function:

◆ setInput()

void aud.util.LexicalScanner.setInput ( String input )

set input (resets scanner state)

Definition at line 84 of file LexicalScanner.java.

                                     {
    input_=input;
  }

Member Data Documentation

◆ END_OF_INPUT

final int aud.util.LexicalScanner.END_OF_INPUT = -1

static

no more input

Definition at line 22 of file LexicalScanner.java.

Referenced by aud.example.graph.GraphParser.graph(), aud.example.expr.Tokenizer.main(), and aud.util.LexicalScanner.main().

◆ NO_MATCH

final int aud.util.LexicalScanner.NO_MATCH = -2

static

no match (usually implies a syntax error)

Definition at line 24 of file LexicalScanner.java.

Referenced by aud.example.expr.Tokenizer.main(), and aud.util.LexicalScanner.main().

◆ P_FLOAT

final Pattern aud.util.LexicalScanner.P_FLOAT

static

Initial value:

=

Pattern.compile("[-+]?[0-9]*\\.?[0-9]+([eE][-+]?[0-9]+)?")

floating point number

Definition at line 60 of file LexicalScanner.java.

◆ P_IDENTIFIER

final Pattern aud.util.LexicalScanner.P_IDENTIFIER

static

Initial value:

=

Pattern.compile("[_a-zA-Z]?(\\w|_)+")

identifiers

Definition at line 57 of file LexicalScanner.java.

◆ P_WHITESPACE

final Pattern aud.util.LexicalScanner.P_WHITESPACE = Pattern.compile("\\s+")

static

white space

Definition at line 55 of file LexicalScanner.java.

Referenced by aud.util.LexicalScanner.eatWhiteSpace().

The documentation for this class was generated from the following file:

LexicalScanner.java
