aud.example.expr.ExpressionTree Class Reference

Tree representation of arithmetic expression. More...

Inheritance diagram for aud.example.expr.ExpressionTree:

Collaboration diagram for aud.example.expr.ExpressionTree:

Public Member Functions
	ExpressionTree (AtomicExpression atom, ExpressionTree left, ExpressionTree right)
	creare and link tree node More...
	ExpressionTree (AtomicExpression atom)
	create tree node More...
double	getValue ()
	compute value of expression More...
void	setData (AtomicExpression data)
	Set AtomicExpression for this node. More...
String	toString ()
	Get string presentation of node data. More...
GraphvizDecorator	getDecorator ()
	get decoration or null More...
Public Member Functions inherited from aud.BinaryTree< T >
	BinaryTree (T data)
	create new root node without children More...
	BinaryTree (T data, BinaryTree< T > left, BinaryTree< T > right)
	create new root node with children More...
BinaryTree< T >	setLeft (BinaryTree< T > tree)
	set left subtree More...
BinaryTree< T >	setRight (BinaryTree< T > tree)
	set right subtree More...
void	setData (T data)
	set node data More...
T	getData ()
	get node data More...
BinaryTree< T >	getParent ()
	get node's parent or null for root More...
BinaryTree< T >	getLeft ()
	get left child or null More...
BinaryTree< T >	getRight ()
	get right child or null) More...
boolean	isRoot ()
	Iscode this} root? More...
boolean	isLeaf ()
	Is this a leaf? More...
BinaryTree< T >	getRoot ()
	traverse upwards to find root node More...
BinaryTreeTraversal< T >.Preorder	preorder ()
	Get preorder iterator over nodes in tree . More...
BinaryTreeTraversal< T >.Inorder	inorder ()
	Get inorder iterator over nodes in tree . More...
BinaryTreeTraversal< T >.Postorder	postorder ()
	Get postorder iterator over nodes in tree . More...
BinaryTreeTraversal< T >.Levelorder	levelorder ()
	Get level-order iterator over nodes in tree . More...
String	toDot ()
	Get dot representation. More...
String	toText ()
	get multiline text visualization More...
String	toTikZ ()
	get TikZ code for LaTeX export More...
String	toDot ()
	Get dot representation. More...
GraphvizDecorator	getDecorator ()
	get decoration or null More...

Static Public Member Functions
static void	main (String[] args)
	test and example for usage More...
Static Public Member Functions inherited from aud.BinaryTree< T >

Additional Inherited Members
Protected Member Functions inherited from aud.BinaryTree< T >
String	dotLabel ()
String	textLabel ()
	Get string representation of data in toText. More...
String	tikzNodeStyle ()
String	toTikZ (int level)

Detailed Description

Tree representation of arithmetic expression.

Each node is associated with an AtomicExpression, which can be either an Terminal or an Operator.

See also

AtomicExpression

Definition at line 14 of file ExpressionTree.java.

Constructor & Destructor Documentation

ExpressionTree() [1/2]

aud.example.expr.ExpressionTree.ExpressionTree	(	AtomicExpression	atom,
		ExpressionTree	left,
		ExpressionTree	right
	)

creare and link tree node

Definition at line 16 of file ExpressionTree.java.

                                                                  {
    super(atom,left,right);
    if (atom.node_!=null)
      throw new RuntimeException("ExpressionTree: AtomicExpression "+
                                 "is already bound to another node!");
    atom.node_=this;
  }

References aud.example.expr.AtomicExpression.node_.

ExpressionTree() [2/2]

aud.example.expr.ExpressionTree.ExpressionTree

(

AtomicExpression

atom

)

create tree node

Definition at line 25 of file ExpressionTree.java.

                                               {
    this(atom,null,null);
  }

Member Function Documentation

getDecorator()

GraphvizDecorator aud.example.expr.ExpressionTree.getDecorator

(

)

get decoration or null

Reimplemented from aud.BinaryTree< T >.

Definition at line 70 of file ExpressionTree.java.

                                                    {
    return decorator;
  }

Referenced by aud.example.expr.ExpressionTreeTraversal.ExpressionTreeTraversal().

Here is the caller graph for this function:

getValue()

double aud.example.expr.ExpressionTree.getValue

(

)

compute value of expression

Exceptions

UnsupportedOperationException

if value cannot be determined

Returns

value obtained from getData()

See also

AtomicExpression::getValue

Definition at line 34 of file ExpressionTree.java.

{ return getData().getValue(); }

References aud.BinaryTree< T >.getData().

Referenced by aud.example.expr.ExpressionTree.main(), and aud.example.expr.ExpressionTreeExample.main().

Here is the call graph for this function:

Here is the caller graph for this function:

main()

static void aud.example.expr.ExpressionTree.main ( String[]  args )

static

test and example for usage

Reimplemented from aud.BinaryTree< T >.

Definition at line 76 of file ExpressionTree.java.

                                         {
    ExpressionTree t=new ExpressionTree
      (new Minus(),
       new ExpressionTree
       (new Times(),
        new ExpressionTree(new Plus(),
                           new ExpressionTree(new Number(2)),
                           new ExpressionTree(new Number(3))),
        new ExpressionTree(new Number(4))
       ),
       new ExpressionTree(new Number(5))
      );

    System.out.println(t);
    System.out.println(t.getValue());
    System.out.println(t.postorder().toString());

    t=new ExpressionTree(new Plus(),
                         t,new ExpressionTree(new Symbol("x")));
    System.out.println(t);
    System.out.println(t.getValue()); // throws
  }

References aud.example.expr.ExpressionTree.getValue(), aud.BinaryTree< T >.postorder(), and aud.BinaryTreeTraversal< T >.Traversal.toString().

Here is the call graph for this function:

setData()

void aud.example.expr.ExpressionTree.setData

(

AtomicExpression

data

)

Set AtomicExpression for this node.

Applies missing "uplink" to node for, i.e., this method manipulates its argument!

For this reason prefer constructing a new node/tree!

Definition at line 43 of file ExpressionTree.java.

                                                       {
    if (data.node_!=null)
      throw new RuntimeException("ExpressionTree#setData: AtomicExpression "+
                                 "is already bound to an ExpressionTree node!");
    super.setData(data);
    data.node_=this; // Note: Side effect on data!
  }

References aud.example.expr.AtomicExpression.node_.

toString()

String aud.example.expr.ExpressionTree.toString

(

)

Get string presentation of node data.

This method only encodes the node's content as string, it does not encode the entire tree! (This makes it easier to, e.g., print out a Stack of nodes.)

Returns

getData.toString

See also

BinaryTreeTraversal.Traversal::toString

Reimplemented from aud.BinaryTree< T >.

Definition at line 51 of file ExpressionTree.java.

                                     {
    if (getData().isTerminal())
      return getData().toString();

    assert(!isLeaf());
    assert(getData().isOperator());

    String term=(!isRoot() ? "(" : "");
    if (getRight()!=null)
      term+=getLeft().toString()+getData().toString()+getRight().toString();
    else
      term+=getData().toString()+getLeft().toString(); // unary operator

    if (!isRoot()) term+=")";

    return term;
  }

References aud.BinaryTree< T >.getData(), aud.BinaryTree< T >.getLeft(), aud.BinaryTree< T >.getRight(), aud.BinaryTree< T >.isLeaf(), and aud.BinaryTree< T >.isRoot().

Here is the call graph for this function:

---

The documentation for this class was generated from the following file:

• ExpressionTree.java
